Bruker DPP1 - Software Interface; PCI Bus Interface

Description
Technical Manual Version 001 BRUKER BIOSPIN 21 (55)
Software Interface 5.4
PCI Bus Interface 5.4.1
PCI Configuration Space
The values of these registers are loaded out of the EEPROM at power–up, togeth-
er with some values from the local bus configuration registers.
Bit 48 47 46 45 44 43 42 ... 33 32 ... 17 18 ... 1
Field PA
R
Default word of the idle state.
Value 1 Last word = 1
Configuration
Space
Address
Register Description Bits
Register
Values
Value
Description
02h Device ID [31:16] 9030 h
00h Vendor ID [15:0] 10B5 h
06h PCI Status [31:16] 0010 h
04h PCI Command [15:0] 0000 h
0Ah Class Code [31:8] 0680 00 h
08h Revision [7:0] 000A h
10 h Base Address 0: Memory access to
Local
Bus Configuration Register
[31:0] FFFF FF80 h 128 byte
14 h Base Address 1: I/O access to
Local
Bus Configuration Register
[31:0] FFFF FF80 h 128 byte
18 h Base Address 2: Memory access to
Local
Bus CS0
[31:0] FFF0 0000 h 1MB range
1C h Base Address 3: Memory access to
Local
Bus CS1
[31:0] FFFF 0000 h 64K range
20 h Base Address 4: Memory access to
Local
Bus CS2
[31:0] FFFF 0000 h 64K range
24 h Base Address 5: Memory access to
Local
Bus CS3
[31:0] FFFF 0000 h 64K range
28 h Not supported
