After initializing the LVDS transmitter it is necessary to reset the input FIFO of the
receiving unit.
Format of the Information Register
Format of the ADR Debug Register
Table 5.39: Information Register Bit Fields
Bits
10..6 5 4..0
Fields
PR6 Version NV Lock NV Register
Table 5.40: Information Register Bit Field Description
Field Value Description
NV Lock
0
1
Default is 1.
Locked. The phase of the NV clock is shifted to the edge of the LVDS clock.
Unlocked.
Table 5.41: ADR Debug Register Bit Fields
Bits
10..1 0
Fields
Fixed value NG_SM_ERR
Res
11 0000 0000 0
Table 5.42: ADR Debug Register Bit Field Description
Field Value Description
NG_SM_ERR 0
1
The phase acquisition NV clock to the LVDS clock is correct.
The LV clock edge was not correctly determined.
