Table 5.37: Control Register Bit Field Description
Field Value Description
INT
0
1
Rising edge detect on NV– value clock.
Interrupt.
No interrupt.
CALC
0
1
Calculation status of preemphasis.
No calculation.
Calculation in progress.
TIME OUT
0
1
Time out error of calculation.
No time-out.
Calculation still in progress at next NV clock.
SEND EN
0
1
Enable or not of sending data to the gradient amplifier.
Disabled.
Enabled, triggered by each NV clock the DPP sends 1 NG word and a com-
plete set of gradient words out of the FIFO. Exception, no NG word is sent at
the first NV clock after SEND EN=1.
REC EN
0
1
Enable or not reading the received gradient data from the gradient controller.
Disabled.
Enabled.
NG OFF
1
Enables transmitting of FIFO content to the gradient amplifier without NG
words if SEND EN=0.
Enabled.
Table 5.38. Format of the Reset Register
Res_Log Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 = Reset
CPLD
Logic
NV_SYNC LVDS
Deskew
Preset
FIFO
OUT
Preset
FIFO IN
TIMEOUT CALC INT
0 = Reset
Output
FIFO
0 =
Reset
Int.
0 = Reset
LVDS
Transmitter
0 = Reset
Calculation
0 = Reset
Next Value
synchronisation
0 = Reset
Calculation
Counter
0 = Reset
Receiver
FIFO
