Bruker DPP1 - Description of the Global Control Register; Table 5.29: Bit Fields for the Space Control Register

38 (55) BRUKER BIOSPIN Technical Manual Version 001
Description
Description of the Global Control Register
The space control registers correspond to the CE memory spaces supported by
the EMIF. There are four CE space control registers that correspond to the four
external CE signals. The MTYPE field identifies the memory type for the corre
-
sponding CE space. If the MTYPE field selects an asynchronous type, the
remaining register fields specify the shaping of the address and control signals for
the access to that space. The MTYPE field should only be set during system ini
-
tialization. The exception is when CE1 is used for the ROM boot mode. In this
case the CE space can be configured to another asynchronous memory type.
6 Reserved A value written to this bit field location has no effect. The reserved bit location
is always read as 1.
5 EKEN Enable bit.
0 ECLKOUT is held low.
1 ECLKOUT is enabled to clock (default).
4 CLK1EN Enable bit
0 Not available on C6713. This bit must be programmed to zero for proper
operation.
3 CLK2EN Enable / disabled using SSCEN / SDCEN bits.
0 CLKOUT2 is held high.
1 CLKOUT2 is enabled to clock (default).
31..12 Reserved A value written to this bit field location has no effect. The bit field is always
read as 0.
CECTL0 0180 000 Global Control Register for CE0 R/W 31-0
CECTL1 0180 000 Global Control Register for CE1 R/W 31-0
CECTL2 0180 000 Global Control Register for CE2 R/W 31-0
CECTL3 0180 000 Global Control Register for CE3 R/W 31-0
Table 5.29: Bit Fields for the Space Control Register
Bits
3
1
.. 2
8
2
7
.. 2
2
2
1
2
0
1
9
.. 1
6
1
5
1
4
1
3
.. 8 7 .. 4 3 2 1 0
Fields
Write setup Write
strobe
Write
hold
Read setup TA Read
strobe
MTYPE r
e
s
Read
hold
Res.
1111 111111 11 1111 11 111111 0000 0 011
Table 5.28: Bit Field Description
