Local Bus Address Map 5.4.4
Flash Prom at the Local Bus 5.4.5
Bus characteristics for accessing Flash PROM‘s:
Bus width: Two byte, data bit 7...0 attached; data bit 15...8 not used; there-
fore the flash prom occupies the double address area.
Cycle Control: Clock controlled.
Cycle Length: Approximately 85 nanoseconds for posting and 270 nanosec-
onds for the reading cycle.
Table 5.7: Local Bus Control Registers
PCI Addr.
Offset
Register Description Register Name
Register
Values
4C Interrupt Control / Status INTCSR 0030 0048 h
50 h PCI Target Response, Serial EE-PROM,
Initialization Control
CNTRL 1078 0000 h
54 h General Purpose I/O Control GPIOC 0024 EB40 h
70 h Hidden 1 Power Management Data Select PMDATA 0 h
74 h Hidden 2 Power Management Data Scale PMCSR[14:13] hidden,
PMCSR[7:0] used
0 h
Table 5.8: Local Bus Address Map
Acronyms
Local
Address
Space Function Mode R/W Bit
0000 CS0 DSP HPI Control Register low word R/W 15–0
0002 CS0 DSP HPI Control Register high word R/W 15–0
0004 CS0 DSP HPI Address Register low word R/W 15–0
0006 CS0 DSP HPI Address Register high word R/W 15–0
0008 CS0 DSP HPI Data Register low word R/W 15–0
000A CS0 DSP HPI Data Register high word R/W 15–0
0000 CS1 Pipeline Register W 31–0
0000 CS2 DSP Reset W xxxx
0000 – FF CS3 Flash Memory W/R 15–0
