Description
Technical Manual Version 001 BRUKER BIOSPIN 25 (55)
0C h Local Address Space 3 Range LAS1RR FFFF 0000 h 64 kB Local Memory
Space, non-prefetch
10 h Expansion Rom Range EROMRR 0000 h Disable
14 h Local Address Space 0 Local
Base Address (Remap)
LAS0BA 0000 0001 h enable CE 0; Base=0h
18 h Local Address Space 1 Local
Base Address (Remap)
LAS1BA 0000 0201 h enable CE 1;
Base=200h
1C h Local Address Space 2 Local
Base Address (Remap)
LAS2BA 0000 0401 h enable CE 2;
Base=400h
20 h Local Address Space 2 Local
Base Address (Remap)
LAS3BA 0001 0001 h enable CE 3;
Base=10000h
24 h Expansion Rom Local Base Ad-
dress (Remap)
EROMBA 0001 0000 h Disable
28 h Local Address Space 0 Bus
Region Descriptor
LAS0BRD 4040 0022 h Ready Input enable 16
Bit Local Bus Width
2C h Local Address Space 1 Bus
Region Descriptor
LAS1BRD 4040 8820 h 16 Bit Local Bus Width,
NRDD 1, NWAD 1,
Write Hold 1
30 h Local Address Space 2 Bus
Region Descriptor
LAS2BRD 4040 8820 h 16 Bit Local Bus Width,
NRDD 1, NWAD 1,
Write Hold
Table 5.6: Local Bus Configuration Registers
