1.2 TS55 Sensor Assembly
The TS55 sensor assembly must be installed as close as possible to the elastic yarn application point.
A = Sensor cable junction board (see paragraph 1.4 – TS55 Sensor Connection)
B = TS55 Sensors
A
A
B
B
