btsr MATRIX CUBE - Configuration of DIAPER FEEDER Devices; Configuration of TS55 Sensors

Installation and Connections
MATRIX CUBE - 15 -
 Parameters P03, P04, P05 and P06 can be directly programmed on SM-DIN/DUOLOOP Board, or
(preferably) on SMART MATRIX CUBE terminal during the style programming stage.
See section 2.
1.10 Configuration of DIAPER FEEDER Devices
Even though the operating parameters of DIAPER FEEDER devices can be programmed locally using the
built-in Keyboard and Display, for SMART MATRIX CUBE application the programming is carried out using
the SMART MATRIX CUBE terminal.
1.11 Configuration of TS55 Sensors
The configuration of TS55 operating parameters is carried out using the SMART MATRIX CUBE terminal.
 For more details about the programming of DIAPER FEEDER devices and TS55 sensors, please
refer to Section 2.
Display
Keyboard
