86
Specifications
Check www.buffalotech.com for information about the latest products and specifications.
LAN Port
Interface
IEEE 802.3ab (1000BASE-T)
IEEE 802.3u (100BASE-TX)
IEEE 802.3 (10BASE-T)
Transfer Speed
1000 Mbps Full duplex (auto-negotiation)
100 Mbps Full duplex/Half duplex (auto-negotiation)
10 Mbps Full duplex/Half duplex (auto-negotiation)
Number of Ports 1 Port (supports AUTO-MDIX)
Connector Type RJ-45 8-pin
Protocol TCP/IP
Access Method CSMA/CD
File Sharing SMB/CIFS, AFP, FTP
Management HTTP/HTTPS
Jumbo Frame
1518/4102/7422/9216 bytes
(Including 14 bytes of the header and 4 bytes of FCS)
USB Port
LS420D, LS410D: USB 2.0 Port (Series A) x 1
LS421DE: USB 2.0 Port (Series A) x 1, USB 3.0 Port (Series 1) x 1
Note: Compatible USB devices include printers, USB UPS devoces, and Buffalo USB
hard drives.
Internal Hard Drive
If a hard drive in your LS420D and LS421DE malfunctions, replace it with a Buffalo OP-
HD/LS series of the same capacity, available from www.buffalotech.com.
Power Supply AC 100 - 240 V, 50/60 Hz
Power Consumption
LS410D: max ~24 W
LS420D: max ~48 W
LS421DE: max ~48 W
Dimensions (WxHxD) /
Weight
LS410D: 45 x 128 x 205 mm (excluding protruding parts)/ ~1.3 kg (2.8 lb.)
LS420D: 87 x 128 x 205 mm (excluding protruding parts)/ ~2.4 kg (5.2 lb.)
LS421DE: 87 x 128 x 205 mm (excluding protruding parts)/ ~2.4 kg (5.2 lb.)
Operating Environment
Temperature: 5-35°C; 41-95°F
Environment humidity: 20-80% (no condensation)
Compatibility
Windows and Mac computers with Ethernet interface
Note: The LinkStation requires an Ethernet connection with your computer for
operation. It cannot be connected via USB.
Supported OS
Windows 8
*
, Windows 7
*
, Windows Vista
*
, Windows XP, Windows 2000, Windows XP
Media Center Edition (2004 or 2005), Windows Server 2012, Windows Server 2008
OS X 10.8, 10.7, 10.6
*32-bit and 64-bit
Compliance Information
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
