SECTION 3 - LUBRICATION AND MAINTENANCE
3-52
EVERY 1000 HOURS
Inspect the seal, 1, on both new elements before
installing. Cracks or chips in the element sealing
rubber indicate that the element is defective and
must be replaced.
Figure 3-75
1
Install the elements into the canister. Be sure that
the seal on the end of the filters fully contacts the
air cleaner body. The wing nuts, 1, have a small
seal on the inner face which should be in good
condition before the wing nuts are tightened. If
the seals on the wing nuts are damaged, replace
them. Tighten the nuts securely.
NOTE: Contact your Buhler Versatile dealer
to obtain the correct filter part numbers.
Figure 3-76
1
OPERATION 51
Change the Cab Air Filter
The cab air filter, 1, located on the rear of the c ab
must be changed periodically to keep the cab air
system operating at maximum efficiency.
Figure 3-77
1
