SECTION 1 - GENERAL INFORMATION
1-22
FOOT AND FLOOR CONTROLS
1 Clutch control pedal
2 Brake pedal
3 Decelerator pedal
Figure 1-24
1
2
3
Figure 1-25
OVERHEAD CONTROLS
1 Air duct
2 Speaker (2)
3 Air conditioner on/off switch
4 Fan rotary select switch
5 Temperature control rotary select switch
6 Recirculation baffle rotary control
7 Recirculation vent (2)
8 Auxiliary three-pin connector
9 Rearview mirror
