SECTION 5 - SPECIFICATIONS
5-8
TURNING GEOMETRY
Turnaround diameter is measured from the center point of the front axle and is a measurement of how
far a tractor will move with each turn. The turnaround diameter is based solely on articulation
angle and is not a function of tire size or configuration.
Articulation Angle Turnaround Diameter
42° 8.69 m (342″)....................................................................
38° 9.73 m (383″)....................................................................
33° 11.33 m (446″)...................................................................
31° 11.73 m (462″)...................................................................
MAXIMUM A LLOWABLE MACHINE WEIGHT
The following table shows the maximum allowable weight of each tractor model.
Model
Maximum Weight
2290 13,154 kg (33,000 lbs.)...................................................................
2335 14,545 kg (36,000 lbs.)...................................................................
2360 15,422 kg (38,000 lbs.)...................................................................
2375 17,273 kg (39,000 lbs.)...................................................................
2425 19,958 kg (44,000 lbs.)...................................................................
TRACTOR SHIPPING WEIGHT
Shipping weight of a tractor can be calculated based on the standard equipment and options ordered
(or dealer installed) before
any liquid ballast is added to the tractor. To calculate the shipping weight,
pick the appropriate front, rear, and total weight values from the following tables (A-F). Once the
shipping weight is found, the tractor can be ballasted and the tire air pressure set. See “Ballasting” in
Section 2. Example:
Tractor: 2375 tractor with powershift transmission, 20.8 x 42 R1 drum-style duals, PTO, 1/2 tank of fuel.
Table Info Front Axle Rear Axle Total
Weight Weight Weight
kg (lbs.) kg (lbs.) kg (lbs.)
A 5,924 (13,059) 2,624 (5,785) 8,548 (18,844)............................ ........... ...........
B 1,521 (3,354) 1,521 (3,354) 3,043 (6,708)............................ ............ ............
C N/A N/A N/A................................ ..................... ....................
D 227 (500) 227 (500)) 453.6 (1,000).............................. ............... ..............
E (-41) (-90)) 494 (1,090) 454 (1,000)............................. .............. ..............
F 226 (498) 164 (361) 390 (859).............................. ............... ...............
Totals 7,857 (17,321) 5,030 (11,090) 12,887 (28,411)........................ ........... ...........
NOTE: The weights shown in tables A -F are calculated values. Exact weights are only
obtainable by putting the tractor on a scale.
