SECTION 1 - GENERAL INFORMATION
1-36
HAULING THE TRACTOR ON A TRANSPORTER
1. Haul the tractor with all four wheels on a
flatbed trailer or truck.
2. Remove the outer duals or triples during
hauling unless special permits allow for
over-width hauling. Consult local authorities
for information on over-width hauling.
3. Make an accurate measurement of the
highest point on the tractor when it is on the
flatbed of the truck. Consult local authorities
regarding over height hauling based on the
measurement taken.
4. Tie-down brackets are located on either side
of the drawbar cage, 1, to allow a chain of
adequate size to be routed through the
brackets and hold down the rear end of the
tractor.
Figure 1-52
1
5. There are cutout slots, 1, on either side of the
front frame of the tractor to allow a chain hook
to fasten the front end of the tractor down.
6. Always install the articulation lock pin and set
the park brake while transporting the vehicle.
Figure 1-53
1
