Buhler Versatile 2290 - Controls and Instruments; Overview of Location and Function

SECTION 1 - GENERAL INFORMATION
1-20
CONTROLS AND INSTRUMENTS -
OVERVIEW OF LOCATION AND FUNCTION
The information on the following pages
identifies, locates and briefly describes the
function of the controls and instruments located
in the cab.
The controls have been divided into the
following six areas:
1. Forward operator controls
2. Foot and floor controls
3. Overhead controls
4. Right side console controls
5. Additional cab controls
6. Operator seat controls
IMPORTANT: The following information in this
section provides a general overview of location
of the controls, but does not provide detailed
operational information. Thoroughly read
Section 2 - “Operation” for details on how to use
the controls and read the instruments before
operating the tractor.
WARNING: DO NOT OPERATE THE
TRACTOR UNTIL YOU ARE THOROUGHLY
FAMILIAR WITH THE LOCATION AND
OPERATION OF ALL CONTROLS.
