SECTION 1 - GENERAL INFORMATION
1-10
PROTECTIVE SHIELDING
ENGINE SIDE COVERS
The side covers, 1, protect the operator from
heated and/or moving parts. Do not operate the
tractor without the engine side covers in place
and latched.
Figure 1-14
1
BATTERY COVER
The battery cover, 1, protects the batteries from
damage and the electrical connections from
accidental contact. The battery cover must
always be in place and latched during operation.
Figure 1-15
1
STARTER SOLENOID SHIELD
The shield, 1, covers the starter solenoid
electrical connections to prevent accidental
contact. The shield must be installed whenever
the batteries are c onnected to the electrical
system.
DANGER: NEVER ATTEMPT TO START THE
TRACTOR BY BYPASSING THE WIRES TO
THE STARTER MOTOR.
Figure 1-16
19992828
1
