SECTION 1 - GENERAL INFORMATION
1-11
MASTER PTO SHIELD
The shield, 1, covers the PTO stub shaft, if so
equipped. The shield does not pivot or lift up.
CAUTION: DO NOT REMOVE OR MODIFY
THE PTO SHIELD.
Figure 1-17
1
CENTER PTO ARTICULATION
DRIVE SHAFT SHIELD
The shield, 1, covers the PTO drive shaft, if so
equipped, as it passes through the articulation
area.
CAUTION: DO NOT REMOVE OR MODIFY
THE PTO SHIELD.
WARNING: INSTALL PROTECTIVE SHIELDS
BEFORE STARTING OR OPERATING THE
TRACTOR.
Figure 1-18
1
