SECTION 3 - LUBRICATION AND MAINTENANCE
3-78
AS REQUIRED
Rear Fender Height Adjustment
Rear fender height can be adjusted to two
positions by removing the four bolts, 1, that
attach the fenders to the rear frame. Move the
fender to the desired height and reinstall the
bolts. Torque the bolts to 165 N⋅m (125 ft. lbs.).
Figure 3-130
1
