5.3. Construction of the SE32 with
sensor-fitting S077
A
B
A: Sensor-fitting type S077
including the flow sensor with oval
gears.
Operating Instructions for the S077
sensor-fitting are available under
www.burkert.com
B: Flow transmitter / flow threshold
detector type SE32 (see chap. 5.1).
5.4. Description of the rating plate
FLOW: SE32/8032 PV HALL
SUPPLY:12-36V... 80mA
REL: 30V or 60V...
PV:12-36V / 4-20mA IP65
0.3-10m/s
S-N:1110
00560547 W45LP
Made in France
2
3
4
6
8
12
7
5
1
1113
14
10
9
1. Measured process value and type of the device
2. Type of sensor
3. Power supply with maximum current consumption
4. Data of the on/off output
5. Protection class of the device
6. Data of the current output
7. Conformity marking
8. Symbol showing that the system is protected with a double
insulation or a reinforced insulation
9. Manufacturing code
10. Warning:
Before using the device, take into account the technical speci-
fications given in the Operating Instructions
11. Measurement range of the flow rate
12. Article number
13. Serial number
14. Certification
Fig. 1 : Rating plate (example)
