12
Technical data
6.1.4. Material data
Part Material
Housing / cover PC, glass fiber reinforced
Front panel folio / Screws Polyester / stainless steel
Cable plug / M12 connector PA / PA or CuZn, nickel-plated
Rating plate Polyester
6.1.5. Electrical data
Power supply
• 12...36 V DC
• filtered and regulated
• oscillation rate: ±10 %
• Connection to main supply:
permanent (through external
SELV and through LPS
power supply)
Specifications of the power
source (not supplied)
• Limited power source according
to UL / EN 60950-1 standards
• or limited energy circuit
according to UL / EN 61010-1,
Paragraph 9.4
Maximum current consumption
• version with transistor output • 50 mA
• version with 1 single relay output • 70 mA
• version with 1 single current
output
• 70 mA
• version with 1 relay and
1 current outputs
• 80 mA
• Drain current (UL device) • 30...50 mA
Protection against polarity
reversal
yes
Transistor output
• NPN and/or PNP,
700 mA max., operation
and thresholds can be
parametered
- NPN output: 0.2...36 V DC
- PNP output: supply voltage
• protection against short
circuits
Relay output (non UL device)
• single
• relay output +
4...20 mA current output
• 3 A / 250 V AC
or 3 A / 30 V DC,
operation and thresholds can
be parametered
• 3 A / 48 V AC
or 3 A / 30 V DC,
operation and thresholds can
be parametered
English
Type 8032 - SE32
