6.2.6. Fluid data
Pipe diameter
depends on the sensor-fitting
used;
The appropriate diameter of an
S030 sensor-fitting is deter-
mined using the flow/DN/fluid
velocity diagrams in chap. 7.2.1.
Type of fluid
Refer to the Operating Instruc-
tions of the related sensor-fitting
(S030)
Rate of solid particles
max. 1%
Fluid temperature (see Fig. 2)
• with S030 sensor-fitting in
PVC
• 0...+50 °C
• with S030 sensor-fitting in PP • 0...+80 °C
• with S030 sensor-fitting in
stainless steel, brass or PVDF
• –15...+100 °C
Fluid pressure
• with S030 sensor-fitting in
metal
• PN16
1)
max.
• with S030 sensor-fitting in
plastic
• PN10
1)
max.
Flow rate measurement
• Measuring range • 0.3...10 m/s,
• Measurement deviation
- with standard K-factor of
the S030 sensor-fitting
- ±3% of the measured
value
2)
- with K-factor determined
with a Teach-In procedure
- ±1% of the measured
value
2)
(at the value of the
Teach-In flow rate)
• Linearity
2)
• ±0.5% of the full scale
• Repeatability
2)
• ±0.4% of the measured value
1)
not evaluated by UL
2)
These values were determined in the following reference conditions:
medium = water, water and ambient temperatures 20°C, min. upstream and
downstream distances respected, appropriate pipe dimensions
10
9
8
7
6
5
4
3
2
1
0
-15 0 +20 +40 +60 +80 +100
A
PVDF
PVDF (PN10)
PVC (PN10)
PP (PN10)
11
12
13
14
15
16
PVC + PP
P [bar]
T [°C]
metal (PN16)
Fig. 2 : Fluid temperature / pressure dependency of the 8032,
depending on the material the S030 sensor-fitting is made of
