Installation and wiring
7.2. Fluid installation of the 8032
The 8032 is inserted into an S030 sensor-fitting mounted on the
pipe. The SE32 is assembled on the S030 sensor-fitting by a
quarter-turn rotation system:
1. Install the S030 sensor-fitting on the pipe,
2. Assemble the SE32 with the S030 sensor-fitting,
3. Finalise the installation of the 8032.
7.2.1. Install the S030 sensor-fitting on the
pipe
→ Select an S030 sensor-fitting suitable for the fluid in the pipes.
→ For thus, refer to the calculation tables page 19.
These calculation tables are used to determine the DN of the
sensor-fitting S030 appropriate to the application, according to the
fluid velocity and the flow rate.
The names of the following norms have changed in the
Operating Instructions:
• for the welding ends, norm BS 4825 is renamed
BS 4825-1;
• for the clamp connections:
- norme BS 4825 is renamed BS 4825-3
- norm DIN 32676 is renamed DIN 32676 series A
Danger
Danger due to the operation of the relay outputs of a UL
device in a wet location.
▶ If a UL device is used in a wet location:
- energize the relay outputs with an alternating voltage of max.
16 Vrms and 22.6 Vpeak.
- or energize the relay outputs with a direct voltage of
max. 35 V DC.
Warning
Risk of injury due to nonconforming installation.
▶ The electrical and fluid installation can only be carried out by
qualified and skilled staff with the appropriate tools.
▶ Install appropriate safety devices (correctly rated fuse and/or
circuit-breaker).
▶ Respect the assembly instructions for the sensor-fitting used.
Risk of injury due to unintentional switch on of power supply
or uncontrolled restarting of the installation.
▶ Take appropriate measures to avoid unintentional activation of
the installation.
▶ Guarantee a set or controlled restarting of the process subse-
quent to any intervention on the device.
Make sure that the device runs correctly, plug in and tighten
the connectors.
