13
Technical data
Relay output (UL device)
3 A / 30 V AC / 42 Vpeak
or 1 A / 60 V DC,
operation and thresholds can
be parametered
To use the relay outputs in a
wet location, observe the fol-
lowing safety instruction.
Danger
Danger due to the operation of the relay outputs of a UL
device in a wet location.
▶ If a UL device is used in a wet location:
- energize the relay outputs with an alternating voltage of max.
16 Vrms and 22.6 Vpeak.
- or energize the relay outputs with a direct voltage of
max. 35 V DC.
4...20-mA-current output
(for flow transmitter version)
• Accuracy
• Wiring
• Loop resistance
• Galvanically insulated
• 4 mA adjustment
• 20 mA adjustment
• Response time (10% up to 90%)
• ±0.5%
• 4 wires
• 1300 W at 36 V DC,
1000 W at 30 V DC,
700 W at 24 V DC,
450 W at 18 V DC,
200 W at 12 V DC
• yes
• between 3 and 5 mA
• between 18.5 and 21.5 mA
• 3 s with filter 2 (default setting)
6.2. Technical data of the 8032
6.2.1. Conditions of use
→ See conditions of use of the SE32, chap. 6.1.1, page 11.
6.2.2. Compliance to standards and
directives
The applied standards, which verify conformity with the EU Direc-
tives, can be found on the EU Type Examination Certificate and/or
the EU Declaration of Conformity (if applicable).
English
Type 8032 - SE32
