Adjustment and functions
9.2. Operating levels
All settings may influence the correct running of the
process.
• Note the values of the parameters set in the table at
chap. 9.8.
The device has 2 operating levels:
• the Process level,
• the Configuration level.
The Configuration level comprises the Parameters and Test menus.
Operating level Functions
Process • To read out:
- the measured flow rate
- the switching thresholds
- the value of the 4...20 mA output (flow-
meter only)
• To access the Parameters and Test menus
of the Configuration level
Operating level Functions
Configuration -
Parameters menu
• To make the settings needed for operation:
- flow rate unit,
- transistor or relay output,
- filter,
- bar graph,
- K-factor,
- 4...20-mA-current output (flowmeter only).
• To make the following additional settings:
• backlighting,
• access code to the Parameters and Test
menus.
Configuration -
Test menu
• To test the configuration made in the
Parameters menu with entering of a theo-
retical value.
• To read the frequency of the measured
signal.
• To adjust the 4...20 mA output.
