System description
Auxiliaryfunctions
• Activation and parameter setting with communications software
Function Eect
Reversaloftheeectivedirectionoftheactuator
DIR.ACT
Assignment of the aeration status of the actuator
chamber to the actual position.
Signal split range
SPLTRNG
Standard signal as % for which the valve runs through
the entire mechanical stroke range.
Stroke limit
X.LIMIT
Limit the mechanical stroke range
Limit actuating time
X.TIME
Limit the control speed
Control parameters
X.CONTROL
Parameterize the position controller
Safety position
SAFEPOS
Definition of the safety position
Cable break detection
4)
SIG.ERROR
Congurationofsignallevelfaultdetection
Digital input
4)
BINARY.IN
Congurationofthedigitalinput
Analog output
4)
OUTPUT
Congurationoftheanalogoutput(variant)
Table 4: Auxiliary functions
4) Only for variant without eldbus communication.
