IO-Link
14 IO-LINK
14.1 Information, IO-Link
IO-Link is an internationally standardized IO technology (IEC 61131-9) to enable sensors and actuators to
communicate.
IO-Link is a point-to-point communication with 3-wire connection technology for sensors and actuators and
unshielded standard sensor cables.
To ensure clear communication, the IO-Link devices should not be parameterised simultaneously by the
higher-level controller (PLC) via the IO-Link master and with the Bürkert Communicator (via the service
14.2 Technical specications, IO-Link
IO-Linkspecications  V1.1.2
Supply via IO-Link (M12 x 1, 5-pin, A-coded)
Port Class B
SIO mode no
IODDle      seeInternet
VendorID 0x0078, 120
DeviceID      seeIODDle
ProductID 8694
Transmission speed COM3 (230.4 kbit/s)
PD Input Bits 80
PD Output Bits 40
M-sequence Cap. 0x0D
Min. cycle time 5 ms
Data storage Yes
Max. cable length 20 m
14.2.1 Conguration of the eldbus
Therequiredstart-uplesandthedescriptionoftheprocessdataandacyclicparametersareavailableon
the Internet.
Downloadfrom:
www.burkert.com/Type8694/Software
