Maintenance
18.2 Service at the air intake lter
DANGER!
Riskofinjuryfromhighpressureintheequipment/device.
▶ Beforeworkingonequipmentordevice,switchothepressureanddeaerate/drainlines.
Toprotecttheinternalsolenoidvalvesandtheactuator,thepilotairisltered.
Thedirectionofowoftheairintakelterininstalledstateisfromtheinsidetotheoutsidethroughthelter
material.
Airintakelter
Quick connector
O-ring
Figure 56: Service on the air intake lter
Procedure:
→ Unlockthequickconnectorbypressingtheholdingelementandpullingouttheairintakelter(ifnec-
essary,useasuitabletoolinbetweentherecessesintheheadofthelter).
→ Cleanthelteror,ifnecessary,replacethelter.
→ Check inner O-ring and, if required, clean.
→ Inserttheairintakelterallthewayintothequickconnector.
DANGER!
Riskofinjuryduetoimproperinstallation.
▶ Ensurethattheairintakelterisinstalledcorrectly.
→ Checkthattheairintakelterissecure.
