System description
5.5.2 Functions of the position controller software
Basicfunctions
• Activation via DIP switches
• Parameter setting via communications software
Function Eect
Sealing function
CUTOFF
Valveclosestightoutsidethecontrolrange.Speci-
cation of the value (as %), from which the actuator is
completely deaerated (when 0 %) or aerated (when
100 %)
(see chapter “7.4FunctionoftheDIPswitches”).
Characteristic correction
CHARACT
Linearization of the operating characteristic can be
implemented (see chapter “7.4FunctionoftheDIP
switches”).
Reversaloftheeectivedirectionset-pointvalue
DIR.CMD
Reversaloftheeectivedirectionoftheset-point
value
(see chapter “7.4FunctionoftheDIPswitches”).
Table 2: Basic functions
Basicfunctions
• Activation with buttons or communications software
Function Eect
Standard signal
3)
INPUT
Select set-point value standard signal
Automatic calibration of the position controller
X.TUNE
Reset to factory settings
RESET
Reset to factory settings
Table 3: Basic functions
3) Only adjustable with communications software
Only for variant without eldbus communication.
