Electrical Installation, büS
12 ELECTRICAL INSTALLATION, BÜS
1
2
3
4
5
Figure 41: Pin assignment
Pin Wirecolor Conguration
1 CAN plate/shielding CAN plate/shielding
2 red +24 V DC ±25%, max. residual ripple 10%
3 black GND / CAN_GND
4 white CAN_H
5 blue CAN_L
Table 28: Pin assignment
ForelectricalinstallationwithbüSnetwork,note:
Usea5-pinroundplugandshielded5-corecable.
Theshieldinginthedeviceisnotconnectedtothefunctionalearth.
