25
Technical data
6.9 Factory settings of the positioner
Functions can be activated via DIP switches:
Function Parameter Value
CUTOFF Sealing function below
Sealing function above
2 %
98 %
CHARACT Characteristic correction FREE
10)
DIR.CMD Reversaloftheeectivedirectionset-
point value
O
Table 5: Factory settings
Functions can be activated via communications software:
Function Parameter Value
INPUT Set-point value input 4 – 20 mA, 4-wire
DIR.ACT
Reversaloftheeectivedirectionofthe
actuator
O
SPLTRNG
Function deactivated
Signal split range below
Signal split range above
0 %
100 %
X.LIMIT
Function deactivated
Stroke limit below
Stroke limit above
0 %
100 %
X.TIME
Function deactivated
Actuating time Open
Actuating time Closed
(1 s) values determined by X.TUNE
(1 s) values determined by X.TUNE
After implementation of RESET: 5 s
X.CONTROL Deadband
Openamplicationfactor
Closeamplicationfactor
1,0 %
(1) values determined by X.TUNE
(1) values determined by X.TUNE
After implementation of RESET: 1
SAFEPOS Safety position 50 %
SIG.ERROR
11)
Function deactivated
Cable break detection set-point value Deactivated
BINARY.IN
11)
Digital input function
Operating principle of digital input
Safety position
Normally open
OUTPUT
(variant)
Norm signal output: Parameter
Norm signal output: Type
Position (POS)
4 – 20 mA
Table 6: Factory settings
10) Without change to the settings via the communications software a linear characteristic is stored in FREE.
11) Only for variant without eldbus communication.
english
Type 8694 REV.2
