Operation and function
16.2.9 OUTPUT (variant) -
Conguration of the analog output (only for variant without
eldbus communication)
The function analog output (OUTPUT) only appears in the selection of functions if the positioner has an
analog output (variant) or if no parameters have been read in yet.
The analog output can be used for feedback of the current position or of the set-point value to the control
center.
Function Position (POS) Output of the current position
Set-point value (CMD) Output of the set-point value
Standard signal 4 – 20 mA Selection of the standard signal
0 – 20 mA
16.2.10 Setting the LED mode, device status
User level: installer
Factory setting: valve mode + warnings
Menuorfunction Valuesordescription
Device
> Generalsettings
> Parameter
> StatusLED
Mode
 NAMURmode
 Valvemode
 Valvemode+Warnings
 Fixedcolor
 LEDo
SettingtheLEDmode,devicestatus:
→ Status LED
→ Mode
Possible selection:

NAMURmode
 Valvemode
 Valvemode+Warnings
 Fixedcolor
 LEDo
→ Select mode.
The mode is set.
