Electrical installation 24 V DC
10 ELECTRICAL INSTALLATION 24 V DC
All electrical inputs and outputs of the device are not galvanically isolated from the supply voltage.
Two kinds of connections are used for the electrical bonding of the positioner:
• Cablegland
with cable gland M16 x 1.5 and screw-type terminals
• Multi-pole
with circular plug-in connector M12 x 1, 8-pin
10.1 Safety instructions
DANGER!
Riskofelectricshock.
▶ Beforeworkingonequipmentordevice,switchothepowersupplyandsecuretopreventreactivation.
▶ Observe applicable accident prevention and safety regulations for electrical equipment.
WARNING!
Riskofinjuryfromimproperinstallation.
▶ Installation may be carried out by authorized technicians only and with the appropriate tools.
Riskofinjuryfromunintentionalactivationofthesystemandanuncontrolledrestart.
▶ Secure system from unintentional activation.
▶ Following installation, ensure a controlled restart.
10.2 Electrical installation with circular plug-in connector
DANGER!
Riskofelectricshock.
▶ Beforeworkingonequipmentordevice,switchothepowersupplyandsecuretopreventreactivation.
▶ Observe applicable accident prevention and safety regulations for electrical equipment.
10.2.1 Designation of the contacts Type 8694
6
1
7
5
4
3
2
8
View without body
casing
Circular plug
M12 x1, 8-pin
Figure 35: Circular plug M12 x 1, 8-pin
