Operation and function
16.2.1 DIR.ACT -
Reversal of the eective direction of the actuator
Usethisfunctiontosettheeectivedirectionbetweentheaerationstateoftheactuatorandtheactual
position.
Factorysetting:O(rise)
Rise:  Directeectivedirection(deaerated → 0 %; aerated 100 %)
Case: Inverseeectivedirection(deaerated → 100 %; aerated 0 %)
Actual
position
Aeration
state
deaerated
aerated
increasing
decreasing
Figure 51: DIR.ACT graph
