27
Control and display elements
Body casing
Basic housing
Actuator
Transparent cap
Figure 10: Open positioner
Seal
body casing
Body casing
Basic housing
Figure 11: Position of the seal in the body casing
ATTENTION!
Damageormalfunctionduetopenetrationofdirtandhumidity.
▶ To observe degree of protection IP65 / IP67, screw the transparent cap in all the way.
→ Close the device (assembly tool: 674077
12)
).
12) The assembly tool (674077) is available from your Bürkert sales oce.
english
Type 8694 REV.2
