Control and display elements
Informationaboutthecommunicationssoftware:
Theswitchingpositionofthe DIP switch haspriorityoverthesettingsvia the communications
software.
Ifthevaluesofthesealingfunction(CUTOFF)orthecorrectioncharacteristic(CHARACT)arechanged
viathecommunicationssoftware,thecorrespondingfunctionmustbeactive(DIPswitchessettoON).
Theeectivedirectionoftheset-pointvalue(DIR.CMD)canbechangedviatheDIPswitchesonly.
Ifthecorrectioncharacteristic(CHARACT)isnotchangedviathecommunicationssoftware,alinear
characteristicissavedwhenDIPswitch3issettoON.
Adetaileddescriptionofthefunctionscanbefoundinthechapterentitled“Basicfunctions”.
Seal
body casing
Body casing
Basic housing
Figure 16: Position of the seal in the body casing
ATTENTION!
Breakageofthepneumaticconnectionpiecesduetorotationalimpact.
▶ When unscrewing and screwing in the body casing or transparent cap, do not hold the actuator of the
process valve but the basic housing.
D
amageormalfunctionduetopenetrationofdirtandhumidity.
▶ To observe degree of protection IP65 / IP67, screw the transparent cap in all the way.
→ Close the device (assembly tool: 674077
17)
).
17) The assembly tool (674077) is available from your Bürkert sales oce.
