Control and display elements
7.5.1.1 Valve mode
Displays in valve mode:
• Valve position: open, half-way, closed
• Device status: Error
Valveposition Valveposition
status,color
Devicestatus:Error
status,color
Open is lit yellow
18)
ashesred alternately with yellow
18)
Half-way is lit white
18)19)
ashesred alternately with white
18)19)
Closed is lit green
18)
ashesred alternately with green
18)
Table 10: Valve mode
7.5.1.2 Valve mode + warnings
Displays in valve mode + warnings:
• Valve position: open, half-way, closed
• Devicestatus:failure,functioncheck,outofspecication,maintenancerequired(accordingtoNAMUR)
Valveposition Devicestatus
Status,color Normaloperation
Open is lit yellow
18)
--
Half-way is lit white
18)19)
--
Closed is lit green
18)
--
Table 11: Valve mode + warnings, normal operation
If several device statuses exist simultaneously, the device status with the highest priority is displayed.
Valveposition Devicestatus
Failure Functioncheck Outof
specication
Maintenance
required
Status,
color
Status,color Status,color Status,color
Open ashesred ashesorange ashesyellow ashesblue alternately with yellow
18)
Half-way ashesred ashesorange ashesyellow ashesblue alternately with white
18)19)
Closed ashesred ashesorange ashesyellow ashesblue alternately with green
18)
Table 12: Valve mode + warnings, device status
Forwarningmessages,theLEDsarebrieyswitchedobetweenthechangeofthecolors.
For localizations, the colors are only shown momentarily.
18) Factory setting, selectable colors for the valve position: O, white, green, blue, yellow, orange, red
19) As of rmware A.1.6
