burmeier Lenus - Fitting the side panels

Instruction Manual for Lenus Care Bed
Page 21
3.6 FITTING THE SIDE PANELS
The side panels are fixed to the longitudinal tube of the mattress base using screws.
Proceed as follows:
Position the side panel, as shown, along the longitudinal tube of the mattress
base 1 .
Fasten the side panel to the inner side of the mattress base with the
through-bolts and the washers (4x) 2 .
Repeat steps 3 and 4 for the other side panel.
