Instruction Manual for Lenus Care Bed
Page 84
9 Technical data
All the indicated dimensions and weights in this manual are approximate.
9.1 DIMENSIONS AND WEIGHTS
Mattress base (LxW)
200 x 90 cm (standard)
(optional equipment: 220 x 90 cm) with bed extension
Empty weight
128 kg
Safe working load
225 kg
Total weight of the bed
360 kg, maximum
Max. mattress
dimensions * (LxWxH)
LxW: 200 x 90 cm
Max. height: 15 cm / 19 cm, depending on type of
mattress base (see chapter 4.6)
External dimensions
(LxW)
237 x 98 cm
* More information about mattress:
- Volume weight: at least 38 kg/m
3
- Compression hardness: at least 4.5 KPa (in edge area)
9.2 ADJUSTMENT RANGES
Backrest angle
0° to approx. 70°
Thigh rest angle
0° to approx. 40°
Reverse-Trendelenburg angle
Approx. 12°
Trendelenburg angle
Approx. 12°
Mattress base height
From approx. 15 to approx. 80 cm
