burmeier Lenus - Integrated Bed Extension

Instruction Manual for Lenus Care Bed
Page 50
4.5.6 Integrated bed extension*
This bed is equipped with an integrated bed extension at the foot end of the bed. This
makes it possible to extend the length of the mattress base by approximately 20 cm.
The resulting gap is filled with a support base. The safety side bars must be replaced by
longer ones. A support base and two short side panels must also be fitted.
The bed extension cannot be pulled out properly if someone is lying on the
bed. To prevent the guides from jamming, therefore, the bed extension may
only be pulled out if the bed is unoccupied.
4.5.6.1 Extending the bed
The bed must not be occupied.
1.
For easier installation: raise the bed and apply the brakes.
2.
Remove the bars of the safety sides, see chapter 4.7.
3.
At the foot end, loosen the screws under the mattress base frame on either side
(see next page 1 ) by a few turns (approximately 2 to 3 whole turns).
Attention: Do not completely remove the screws. These screws act as a limit stop
for the foot-end chassis. They make it impossible for the chassis to be pulled
completely out of the mattress base frame.
4.
Release the brakes at the foot end.
6.
Carefully pull the foot-end chassis out as far as the limit stop (approximately
20 cm).
7.
Then tighten the two screws again from below.
8.
Try sliding the foot-end chassis back and forth to check that it is securely fixed.
Check to make sure that the chassis cannot be pulled further out.
7.
Apply the brakes at the foot end.
8.
Place the support base into the resulting space in the mattress base.
9.
Secure the short side panels 2 and the support base from the inside using the two
through bolts (M6x30 mm) and two washers (6.4 mm) (see next page).
10.
Attach the longer safety side bars, see chapter 3.7.
