Instruction Manual for Lenus Care Bed
Page 27
3.9 CONNECTING THE POWER ADAPTER/POWER PLUG
Position the bed so as to allow easy access to the power plug at all times so that the
bed can be disconnected from the mains, if necessary.
3.9.1 Power adapter
Proceed as follows:
Plug the power adapter into a mains socket.
− The cable outlet must hang downwards
(see picture).
− Observe the following safety instructions!
Insert the plug of the low-voltage
cable into the connection socket.
3.9.2 Power plug
Plug the power plug into a mains socket.
Damage to property due to routing cables incorrectly
Cables that are incorrectly laid can cause damage to property when adjustments are
made to the bed.
• Lay all cables carefully.
• Ensure that no cables are damaged, there are no loops and the cables are not
squeezed by moving parts.
• The electricity cable must not be run over by the castors when the bed is moved!
• The cable from the power adapter/power plug must be laid to the connection
socket at the head end in such a way that it lies between the cross tube and the
headboard surround.
Attention: If the cable is laid underneath the cross tube 1 and/or under the brake
lever 2, the cable will be pulled/torn out of the connection socket when the bed is
raised.
