Instruction Manual for Lenus Care Bed
Page 22
3.7 ATTACHING THE SAFETY SIDES
The bed is equipped with safety sides to protect the resident from accidentally falling out
of bed. The safety sides are made of bars with plastic end caps and are attached to the
bed with a simple click-on system. If necessary, they can be manually raised or lowered
by the carer.
On each chassis [3]+[9] there is one guide rail [11] on the left and one on the right. A
safety side guide runs in each of these guide rails. Each guide has two holding devices
for the bars. The safety side guides are pre-assembled at the factory. The safety side
bars can be quickly attached to the holding devices thanks to the simple click-on
system.
Risk of injury and material damage
Improperly installed safety side bars can fall and damage property or cause
minor injuries.
• Use only the safety sides described in this manual. Safety sides are either
factory integrated into the bed or available as accessories.
• After installing each safety side bar, check that it is correctly locked into the
holding devices.
• Operate the safety sides to check that they are correctly fitted and function
properly (see chapter 4.6).
Proceed as follows:
Move all the safety side
guides to the top position a .
Start with the lower
bar: Insert one end of the bar
(plastic end cap) into the
lower holding device at the
head end of the bed.
− Attention: The recess on the
safety side bar must face
inwards and the rounded side
of the bar must face upwards.
