Instruction Manual for Lenus Care Bed
Page 58
4.8 COMFORT MATTRESS BASE, 90 CM WIDE (OPTIONAL EQUIPMENT)
When ordered with a bed extension, 5 additional elements are supplied for the
Comfort mattress base.
Wings of the black elements face
outwards 1
Turn the mounting clips 2 180° until
they are 144 mm in length 3
mm
Fit the mounting clips onto the
struts of the mattress base 4 and
5 , white elements in the middle
and black elements outside.
4
5
1
3
2
