Instruction Manual for Lenus Care Bed
Page 55
4.6.2 Raising the safety sides
1. Raise each of the safety side bars, one after the other, one end at a time, until they
click audibly into the uppermost position at both ends.
2. Push and pull the bars to check that they have been locked in place by the release
buttons.
3. Repeat the procedure for the safety side on the other side of the bed.
4.6.3 Lowering the safety sides
Risk of injury and crushing!
To avoid crushing and injuries when lowering the safety sides, observe the
following instructions:
• Before lowering the safety side, make sure that the resident’s limbs are not
located within the area of movement of the bars.
• Do not allow the safety side bars to fall if the bed is at its lowest position
(approximately 3 cm above the floor). Otherwise, feet located directly below
the bars could be injured.
Raise the safety side bars slightly.
Press the release lever 1
downwards.
