2.7 Technical specifications table
Table 2.3: Mod. N1471 Channel technical specifications
Output channels:
Positive or Negative Polarity (requires internal setting, see § 4.1)
Output ranges:
5.5kV / 300µA
Max. Ch. Output Power:
1.65W
Vset / Vmon Resolution:
100 mV
Iset / Imon Resolution
5
:
If IMON RANGE = High is selected resolution is 5 nA
If IMON RANGE = Low is selected resolution is 0.5 nA
Vmax:
0 ÷ 5600 V
Absolute maximum HV level that the channel is allowed to reach, independently from the preset value
Vset. Output voltage cannot exceed the preset value Vmax. The accuracy is 1 % ± 5 V
Vmax resolution:
± 1 V
Alarm output:
Open collector, 100 mA maximum sink current
Interlock input:
LOW: <1V; current~5mA; HIGH: 4÷6 V
Ramp Up/Down:
1÷500 Volt/s, 1 Volt/s step
Trip:
Max. time an "overcurrent" is allowed to last (seconds). A channel in "overcurrent" works as a current
generator; output voltage varies in order to keep the output current lower than the programmed
value. "Overcurrent" lasting more than set value (1 to 9999) cause s the channel to "trip". Output
voltage will drop to zero either at the Ramp-down rate or at the fastest available rate, depending on
Power Down setting; in both cases the channel is put in the OFF state. If trip= INFINITE, "overcurrent"
lasts indefinitely.
TRIP range: 0 ÷ 999.9 s; 1000 s = Infinite. Step = 0.1 s
Vmon vs. Vout Accuracy:
6
±0.02% of read value ±2V
Vset vs. Vmon Accuracy:
4
±0.02% of read value ±2V
Imon vs. Iout Accuracy:
4
If IMON RANGE = High: ±2% of read value ±20nA
If IMON RANGE = Low:±2% of read value ±2nA
Iset vs. Imon Accuracy:
4
If IMON RANGE = High: ±2% of read value ±30nA
If IMON RANGE = Low:±2% of read value ±3nA
Voltage
Ripple:
7
typical
<5mVpp
maximum
<10mVpp
Humidity range:
0 ÷ 80%
Operating temperature:
0 ÷ 45°C
Storage temperature:
-10 ÷ 70°C
Vout / Temperature coefficient:
max. 50ppm / °C
Imon / Temperature coefficient:
max 100ppm/C°; max 300ppm/C° with Imon X10 zoom (optional)
Long term stability Vout vs. Vset:
± 0.02% (after one week @ constant temperature)
5
The module is calibrated by introducing a positive offset on the current monitor, see details in § 3.3
6
From 10% to 90% of Full Scale Range
7
Measured w ith: 1m cable length; 2nF capacitance
