2 Technical specifications
2.1 Packaging
The Mod. N1471 boa rds are hous ed in s i ngle wi dth NIM module s.
2.2 Power requirements
Table 2.1: Power requirements
Board type
N1471
Channel configuration
without A1480
with A1480
N° ch ON
Current (± 12V)
Current (±6V)
n° ch ON
Current (± 12V)
Current (±6V)
3kV/300µA
4 CH
860 mA
< 10mA
4 CH
750 mA
800 mA
5.5kV/30µA
4 CH
720 mA
< 10mA
4 CH
630 mA
600 mA
5.5kV/300µA
4 CH
1.02 A
< 10mA
4 CH
800 mA
900 mA
Board type
N1471A, N1471AL, N1471AR
Channel configuration
without A1480
with A1480
N° ch ON
Current (± 12V)
Current (±6V)
n° ch ON
Current (± 12V)
Current (±6V)
3kV/300µA
2 CH
620 mA
< 10mA
2 CH
500 mA
500 mA
5.5kV/30µA
2 CH
550 mA
< 10mA
2 CH
440 mA
400 mA
5.5kV/300µA
2 CH
700 mA
< 10mA
2 CH
530 mA
600 mA
Board type
N1471B
Channel configuration
without A1480
with A1480
N° ch ON
Current (± 12V)
Current (±6V)
n° ch ON
Current (± 12V)
Current (±6V)
3kV/300µA
1 CH
530 mA
< 10mA
1 CH
370 mA
400 mA
5.5kV/30µA
1 CH
470 mA
< 10mA
1 CH
340 mA
300 mA
5.5kV/300µA
1 CH
500 mA
< 10mA
1 CH
380 mA
400 mA
WARNING: if the A1480 i s not i nstalled, ±6V power supplies are required only by ol der vers i ons of the N1471;
such boards can be recognized by the presence of power pins 10 and 11 on the backplane NIM connector (s ee
fi gure 2.1). If the A1480 is not i ns tal l ed, new vers i ons opera te only wi th ±12V power s uppli es .
