Bit 1 → RUP
1 : Channel Ramp UP
Bit 2 → RDW
1 : Channel Ramp DOWN
Bit 3 → OVC
1 : IMON >= ISET
Bit 4 → OVV
1 : VMON > VSET + 250 V
Bit 5 → UNV
1 : VMON < VSET - 250 V
Bit 6 → MAXV
1 : VOUT in MAXV protection
Bit 7 → TRIP
1 : Ch OFF via TRIP (Imon >= Iset during TRIP)
Bit 8 → OVP
1 : Power Max; Power Out > 1.7W
Bit 9 → OVT
1: TEMP > 105°C
Bit 10 → DIS
1 : Ch disabled (REMOTE Mode and Switch on OFF position)
Bit 11 → KILL
1 : Ch in KILL via front panel
Bit 12 → ILK
1 : Ch in INTERLOCK via front panel
Bit 13 → NOCAL
1 : Calibration Error
Bit 14, 15 → N.C.
3.5.4 MONITOR commands related to the module
The following table s hows the strings to be us ed to ha ndle monitor commands rel ated to the modul e.
String
Function (Units)
$BD:xx,CMD:MON,PAR:BDNAME
Read out module name ( N1471 )
$BD:xx,CMD:MON,PAR:BDNCH
Read out number of Channels present ( 4 )
$BD:xx,CMD:MON,PAR:BDFREL
Read out Firmware Release ( XX.X )
$BD:xx,CMD:MON,PAR:BDSNUM
Read out value serial number ( XXXXX )
$BD:xx,CMD:MON,PAR:BDILK
Read out INTERLOCK status ( YES/NO )
$BD:xx,CMD:MON,PAR:BDILKM
Read out INTERLOCK mode ( OPEN/CLOSED )
$BD:xx,CMD:MON,PAR:BDCTR
Read out Control Mode (LOCAL / REMOTE )
$BD:xx,CMD:MON,PAR:BDTERM
Read out LOCAL BUS Termination status ( ON/OFF )
$BD:xx,CMD:MON,PAR:BDALARM
Read out Board Alarm status value ( XXXXX )
