3.5.3 MONITOR commands related to the Channels
The following table contains the strings to be used to ha ndle monitor commands re la ted to the Channel s .
The 'X' in the Field 'Cha nnel' ca n be set in the '0..4' range.
When 'X=4' the module returns the val ues of the parameter of all 4 Channels.
String
Function (Units)
$BD:xx,CMD:MON,CH:X,PAR:VSET
Read out VSET value ( XXXX.X V )
$BD:xx,CMD:MON,CH:X,PAR:VMIN
Read out VSET minimum value ( 0 V)
$BD:xx,CMD:MON,CH:X,PAR:VMAX
Read out VSET maximum value ( 8000.0 V )
$BD:xx,CMD:MON,CH:X,PAR:VDEC
Read out VSET number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:VMON
Read out VMON value ( XXXX.X V )
$BD:xx,CMD:MON,CH:X,PAR:ISET
Read out ISET value ( XXXX.XX µA )
$BD:xx,CMD:MON,CH:X,PAR:IMIN
Read out ISET minimum value ( 0 µA )
$BD:xx,CMD:MON,CH:X,PAR:IMAX
Read out ISET maximum value ( 3000.00 µA )
$BD:xx,CMD:MON,CH:X,PAR:ISDEC
Read out ISET number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:IMON
Read out IMON value ( XXXX.XX µA )
$BD:xx,CMD:MON,CH:X,PAR:IMRANGE
Read out IMON RANGE value ( HIGH / LOW )
$BD:xx,CMD:MON,CH:X,PAR:IMDEC
Read out IMON number of decimal digits (2 HR, 3 LR)
$BD:xx,CMD:MON,CH:X,PAR:MAXV
Read out MAXVSET value ( XXXX V )
$BD:xx,CMD:MON,CH:X,PAR:MVMIN
Read out MAXVSET minimum value ( 0 V )
$BD:xx,CMD:MON,CH:X,PAR:MVMAX
Read out MAXVSET maximum value ( 8100 V )
$BD:xx,CMD:MON,CH:X,PAR:MVDEC
Read out MAXVSET number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:RUP
Read out RAMP UP value ( XXX V/S )
$BD:xx,CMD:MON,CH:X,PAR:RUPMIN
Read out RAMP UP minimum value ( 1 V/S )
$BD:xx,CMD:MON,CH:X,PAR:RUPMAX
Read out RAMP UP maximum value ( 500 V/S )
$BD:xx,CMD:MON,CH:X,PAR:RUPDEC
Read out RAMP UP number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:RDW
Read out RAMP DOWN value ( XXX V/S )
$BD:xx,CMD:MON,CH:X,PAR:RDWMIN
Read out RAMP DOWN minimum value ( 1 V/S )
$BD:xx,CMD:MON,CH:X,PAR:RDWMAX
Read out RAMP DOWN maximum value (500 V/S)
$BD:xx,CMD:MON,CH:X,PAR:RDWDEC
Read out RAMP DOWN number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:TRIP
Read out TRIP time value ( XXXX.X S )
$BD:xx,CMD:MON,CH:X,PAR:TRIPMIN
Read out TRIP time minimum value ( 0 S )
$BD:xx,CMD:MON,CH:X,PAR:TRIPMAX
Read out TRIP time maximum value ( 1000.0 S )
$BD:xx,CMD:MON,CH:X,PAR:TRIPDEC
Read out TRIP time number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:PDWN
Read out POWER DOWN value ( RAMP / KILL )
$BD:xx,CMD:MON,CH:X,PAR:POL
Read out POLARITY value ( '+' / '-' )
$BD:xx,CMD:MON,CH:X,PAR:STAT
Read out Channel status value ( XXXXX )
3.5.3.1 Meaning of STATUS bits (value read in decimal Format)
Bit
Function
Bit 0 → ON
1 : ON 0 : OFF
