3.5.4.1 Meaning of Board Alarm bits
Bit
Function
Bit 0 → CH0
1 : Ch0 in Alarm status
Bit 1 → CH1
1 : Ch1 in Alarm status
Bit 2 → CH2
1 : Ch2 in Alarm status
Bit 3 → CH3
1 : Ch3 in Alarm status
Bit 4 → PWFAIL
1 : Board in POWER FAIL
Bit 5 → OVP
1 : Board in OVER POWER
Bit 6 → HVCKFAIL
1 : Internal HV Clock FAIL ( 200±10kHz)
3.5.5 SET commands related to the Channels
The followi ng tabl e contains the s trings to be us ed to handle s et commands related to the Channel s .
The 'X' in the Field 'Cha nnel' ca n be set to the '0..(N-1)' values .
10
When 'X=N' the command i s is s ued to all Cha nnels.
String
Function (Units)
$BD:xx,CMD:SET,CH:X,PAR:VSET,VAL:XXXX.X
Set VSET value
$BD:xx,CMD:SET,CH:X,PAR:ISET,VAL:XXXX.XX
Set ISET value
$BD:xx,CMD:SET,CH:X,PAR:MAXV,VAL:XXXX
Set MAXVSET value
$BD:xx,CMD:SET,CH:X,PAR:RUP,VAL:XXX
Set RAMP UP value
$BD:xx,CMD:SET,CH:X,PAR:RDW,VAL:XXX
Set RAMP DOWN value
$BD:xx,CMD:SET,CH:X,PAR:TRIP,VAL:XXXX.X
Set TRIP time value
$BD:xx,CMD:SET,CH:X,PAR:PDWN,VAL:RAMP/KILL
Set POWER DOWN mode value
$BD:xx,CMD:SET,CH:X,PAR:IMRANGE,VAL:HIGH/LOW
Set IMON RANGE value
11
$BD:xx,CMD:SET,CH:X,PAR:ON
Set Ch ON
$BD:xx,CMD:SET,CH:X,PAR:OFF
Set Ch OFF
3.5.6 SET commands related to the module
String
Function (Units)
$BD:xx,CMD:SET,PAR:BDILKM,VAL:OPEN/CLOSED
Set Interlock Mode
$BD:xx,CMD:SET,PAR:BDCLR
Clear alarm signal
10
N is the number of channels
11
parameter 'IMRANGE' can be changed only on modules featuring IMON zoom (optional)
