Calrec TYPE R - AudioPerformanceSpecifications

130 TYPE R Radio Production System Specifications
ANALOGUE INPUT SPECS (ON UR6500, AD6501 AND AD6502)
AES3 BALANCED DIGITAL INPUTS (ON UR6500, AD6501 AND JD6503)
AES3 BALANCED DIGITAL OUTPUTS (ON UR6500, AD6501 AND JD6503)
Format
AES/EBU (AES3) 24-bit.
Interface, Input Sensitivity
110 Ohm balanced (D-Type), 0.2V-7.0V Pk-Pk
Sample Rate Conversion
24-Bit switchable on all AES inputs, SRC Range 30kHz-100kHz
SRC THD+N
-117dB @ 1kHz, 0.00014%
Format
AES/EBU (AES3) 24-bit
Interface
110 Ohm balanced (D-Type)
Jitter
<0.015UI (2.5ns) peak
Analogue - Digital
Conversion
24 Bit
Input
Electronically Balanced
Input Impedance
5.4k Ohms at mic/line level gain settings
Sensitivity
+18 / -78dB for Mic/Line Inputs
Maximum Input Level
24dBu
Frequency Response
20Hz to 20kHz +/- 0.25dB on Mic/Line Inputs
Distortion
-1dBFS @ 1kHz - Better than 0.005% (-86dB)
-20dBFS @ 1kHz - Better than 0.003% (-90dB)
-40 dBFS @ 1kHz - Better than 0.03% (-70dB)
Dynamic Range(CCIR-RMS)
-116 d B
Idle Channel Noise
-116dBFS (88dBu)
Equivalent Input Noise
-126dB (150 Ohm source)
Input CMR
(Common Mode Rejection)
>90dB at a 52dB gain setting
>75dB at a 4dB gain setting
Crosstalk
-115dB or better on adjacent inputs with 0dBFS tone at 1kHZ on Source
Phantom power current limit
9.5mA / channel
AUDIO PERFORMANCE SPECIFICATIONS
ANALOGUE OUTPUT SPECS (ON UR6500, AD6501 AND AD6502)
Digital - Analogue
Conversion
24 Bit
Output Balance
Electronically Balanced
Output Impedance
31 Ohms
Maximum Output Level
24dBu
Frequency Response
20Hz to 20kHz +/- 0.25dB
Distortion
-1dBFS @ 1kHz - Better than 0.002%(-93dB)
-20dBFS @ 1kHz - Better than 0.003% (-90dB)
-40 dBFS @ 1kHz - Better than 0.03% (-70dB)
Dynamic Range (CCIR-RMS)
-113 d B
Idle Channel Noise
-113dBFS (85dBu)
Crosstalk
-105dB or better on adjacent outputs with 0dBFS tone at 1kHZ on Source
