54 TYPE R Radio Production System Fixing Bracket Assembly Instructions
FADER PANEL LINKING (720-999007)
Fader panel IM6413 to Fader Panel
IM6413 Linking Option:-
FIG 1 FADER PANEL TO FADER PANEL LINKING
FIG 2 LINKING PANEL PROCEDURE
1st Panel 2nd Panel
1st Panel2nd Panel
End View
Screws
Underside View
Top
