Calrec TYPE R - DSP Path and Mix Bus Tables for DSP Packs

81
Type R Console Summary
20 CH 30 CH 40 CH 60 CH 80 CH 120 CH
DSP Paths (mono equivalent)
Channel Paths 20 30 40 60 80 120
Aux Paths 8 8 16 16 16 16
Main & Group Paths 14 14 22 30 30 30
Total DSP Paths 42 52 78 106 126 166
Mix Paths (mono equivalent)
Main 1/PGM1 Paths
14 14 22 30 30 30Main 2/PGM2 Paths
Main 3/REC Paths
Group Paths
Aux Paths 8 8 16 16 16 16
PFL Mix Paths 2 2 2 6 6 6
AFL Mix Paths 2 2 2 6 6 6
Mix Minus Mix Paths 4 4 4 4 4 4
Conference Mix Paths 2 2 2 2 2 2
Total Mix Paths 32 32 48 64 64 64
For dual consoles
Two Consoles powered by one DSP Core: There are 4 variants depending on which DSP packages have been made available from 20
to 80 DSP channels. Mix buses will also vary depending on the DSP channel size with only the largest DSP pack R120 offering 5.1
capability in a dual console arrangement. DSP Pack R20 does not provide a dual console arrangement, R40 and R80 will only provide
mono or stereo paths/channels in a dual console arrangement. It should be noted that even though in some elements of the table
there are 16 Group buses shown as available the system is designed to provide up to a maximum of 8 Groups/console irrespective of
width.
For Single Consoles
Single consoles powered by one DSP Core: There are 4 variants depending on which DSP packages have been made available
from 20 to 120 DSP channels. Mix buses will also vary depending on the DSP channel size with only the two larger DSP packs R80
and R120 offering 5.1 capability in a single console arrangement. DSP Packs NOT 5.1 capable (R20 and R40) will only provide
mono or stereo paths/channels. It should be noted that even though in some elements of the table there are 16 Group buses shown
as available the system is designed to provide up to a maximum of 8 Groups/console irrespective of width.
For triple consoles
Three consoles powered by one DSP Core: There are 3 variants depending on which DSP packages have been made available from
20 to 60 DSP channels.. Mix buses will also vary depending on the DSP channel size with only the largest DSP pack R120 offering
5.1 capability on 1 console in a triple console arrangement. DSP Packs R20 and R40 do not provide a triple console arrangement.
DSP Pack R80 will only provide mono or stereo paths/channels in a triple console arrangement. It should be noted that even though
in some elements of the table there are 16 Group buses shown as available the system is designed to provide up to a maximum of 8
Groups/console irrespective of width.
DSP Path and Mix Bus Tables
The following tables show the DSP path and Mix Path count for the various DSP Packs across different options.
DSP PATH AND MIX PATH SUMMARY TABLE PER CONSOLE SIZE
